Chain Conveyor for Papermaking

Chain Conveyor is mainly used for conveying papermaking raw material. You may have a deep understanding about Chain Conveyor through the following questions.

Q: What’s the advantages of your Chain Conveyor compared with other manufacturers of papermaking industry?
1. One-time impact stamping trough plate to convey papermaking raw material: firm and durable, strong shock resistance
2. Equips hard-surface gear reducer, high safety factor.
3. V type backplate on the two sides of Chain Conveyor can improve the conveying capacity, and make sure that impurities won’t slid to the rollers,which improves service life.

Q: We want to know the detailed information of gear reducer ratio of 1200 Chain Conveyor.
Gear reducer is ZSY200-71 hard-surface type. The ratio of gear reducer speed is 71:1; The reduction ratio of rotor through pulley is 2.8:1; The total reduction ratio is 198.8:1

Q: We want to know the type and safety precautions of Chain Conveyor rotor.
According to the load bearing, the maximum required torque of Chain Conveyor is about 4400N.M, while the maximum torque of our ZSY200 type gear reducer is 10171N.M, which is more than twice larger, so it an maintain that the Chain Conveyor can operate normally and safely.

Leizhan provides various kinds of papermaking and pulp equipment. Welcome to contact us for more details.
