ZFM Flotation Deinking Machine

ZFM Flotation Deinking Machine

ZFM Flotation Deinking Machine is mainly applied to deink recycled pulp. Flotation Deinking Machine can effectively remove the ink, light impurities and stickies, etc.

Application & Features

1. Mainly applied to deink recycled pulp, it can effectively remove the ink, light impurities and stickies, etc.
2. High efficient flotation, high consistency scum, less fiber loss.
3. Easy maintenance, low power consumption, low operation cost.
4. Only one set can achieve 4-5 stages of flotation, has advantages of less occupied area.

Main Specification

Type ZFM 1 ZFM 2 ZFM 3 ZFM 4 ZFM 5 ZFM 6 ZFM 7 ZFM 8 ZFM 9 ZFM 10
Throughout Capacity(m3/h) 256 400 512 624 800 976 1152 1344 1456 1600
Layers 3-5
Consistency(%) 1.1±0.1
Production Capacity(t/d) 55-65 85-100 110-130 130-160 170-210 210-250 240-300 290-350 310-480 340-420
Consistency of Ink(%) 2-3

Download complete technical literature [PDF]
